High resolution: Clear images with a long viewing range
Waterproof and dustproof: IP69 rating; can be directly rinsed with running water
Easy to install: Analog video output; plug-and-play
Share:
Key Parameters
| Specifications | Indicators |
| Output Resolution | 640X512 |
| Field of View | 48°x 37° |
| Frame Rate | ≥25FPS |
| Start-up Time | ≤3.5s（normal temperature） |
| Communication Interface | RS232 |
| Video Output Interface | RCA connector |
| Video Output Format | Emulates CVBS |
| Video Output Resolution | PAL@720 × 576 NTSC@720 × 480 |
| Shutter | Auto Shutter Speed Compensation |
| Input Voltage | TYP 12V (DC 9V -32V ) |
| Power Consumption | ≤1W@(@12V, window defroster off) ≤5W@(@12V, window defroster on) |
| Operating Temperature | －40℃～＋85 ℃ |
| Detection Range | People（1.75*0.5m）≥200m Vehicles（1.75*1.75m）≥400m |
| Dimensions | ≤28*28*55mm |
| Weight | ≤120g |
| IP Rating | IP67&IP69K |
| Certifications | CE Certification |
The product delivers stable imaging in various conditions, including pitch-black nights, intense glare, and haze, thereby reducing the likelihood of traffic accidents and enhancing driving safety.
The product is suitable for aftermarket installation and driver assistance systems in off-road vehicles, specialty vehicles, mining vehicles, freight and logistics vehicles, and port and airport shuttle buses.
Dedicated to the development of global in vehicle infrared technology
If you would like to learn more about safe driving solutions, please contact us
