High Performance: High resolution, sharper images, and smoother playback
Compact Design: Low power consumption and flexible layout
Stutter-Free Algorithm: Smooth playback without lag
Share:
Key Parameters
| Specifications | Indicators |
| Output Resolution | 640X512 |
| Field of View | 48°x 37° |
| Frame Rate | 30FPS |
| Start-up Time | ≤3.5s（normal temperature） |
| Communication Interface | I2C |
| Video Output Interface | Fakra Z (LVDS) |
| Video Output Format | YUV-422-8bit |
| Video Output Resolution | 640X512 |
| Shutter | Supports the no-stop algorithm |
| Input Voltage | DC 9-16V（POC Power Supply） |
| Power Consumption | ≤1.25 W (@12 V, window heating off) ≤4.5 W (@12 V, window heating on) |
| Operating Temperature | －40℃～＋85 ℃ |
| Detection Range | People（1.75*0.5m）≥200m Vehicles（1.75*1.75m）≥400m |
| Dimensions | ≤26*26*48.5mm |
| Weight | ≤90g |
| IP Rating | IP67&IP69K |
| External Trigger | Support |
| Certifications | CE Certification |
Infrared camera products maintain stable imaging in extreme conditions such as total darkness, blinding glare, heavy fog, and dust, ensuring reliable monitoring of the surrounding environment.
These products are suitable for a wide range of vehicle types, including commercial vehicles, construction machinery, mining trucks, logistics vehicles, specialty vehicles, and emergency response vehicles.
Dedicated to the development of global in vehicle infrared technology
If you would like to learn more about safe driving solutions, please contact us
