45° Ultra-Wide-Angle Thermal View: No blind spots on complex roads
ADAS Full-Time Active Warning: Prevent accidents before they happen
Triple AI Detection for People, Vehicles, and Animals
HD Touchscreen + Dashcam in One
Share:
Key Parameters
| Specifications | Indicators |
| Output Resolution | 640 x 512 |
| Field of View | 48° X 37° |
| Frame Rate | ≥25FPS |
| Start-up Time | ≤8.5s（normal temperature） |
| Communication Interface | USB((Type-C port) |
| Video Output Interface | RCA connector |
| Video Output Format | Emulates CVBS，USB(RNDIS) |
| Video Output Resolution | PAL@720 × 576 NTSC@720 × 480 |
| Audio Interface | Supports PWM output to drive an external buzzer |
| Shutter | Auto Shutter Speed Compensation |
| Input Voltage | 1、TYP 12V（DC 9-16V） 2、 USB-powered（4.5V-5.5V） |
| Power Consumption | ≤2W (@12V without window heating enabled) ≤6W (@12V with window heating enabled) |
| Operating Temperature | －40℃～＋85 ℃ |
| Detection Range | People（1.75X0.5m）≥200m Vehicles （1.75X1.75m）≥400m |
| Recognition Range | People（1.75X0.5m）≥90m Vehicles（1.75X1.75m）≥120m |
| Dimensions | Camera: 36 × 36 × 46.5 mm Control box: 100 × 80 × 24 mm |
| Weight | Camera weight: ≤120 g Control box weight: ≤500 g |
| IP Rating | Camera: IP67 & IP69K Algorithm Box: IP5K0 |
| Certifications | CE Certification |
Infrared camera products maintain stable imaging in extreme environments such as pitch-black nights, blinding glare, heavy fog, and dust, enabling reliable perception of the surrounding environment. Based on AI deep learning algorithms, they can also detect and identify targets such as pedestrians, vehicles, and animals in real time, issuing safety alerts to ensure driving safety and improve operational efficiency.
The product is suitable for a wide range of vehicle types, including commercial vehicles, construction machinery, mining trucks, logistics vehicles, special-purpose vehicles, and emergency response vehicles.
Dedicated to the development of global in vehicle infrared technology
If you would like to learn more about safe driving solutions, please contact us
